PPS GF40 SHEET 8MM
Zhejiang Zero Engineering Plastics Co., Ltd. is one of the leading manufacturers and suppliers of pps gf40 sheet 8mm in China. If you're going to wholesale bulk advanced pps gf40 sheet 8mm made in China, welcome to get free sample from our factory. All customized products are with high quality and competitive price.
Products Description
PPS GF40 is a high-performance material that has been specially designed for long-term operation in high temperature environments. This product is made from reinforced polyphenylene sulfide (PPS) and is reinforced with 40% glass fibers to enhance its structural strength and dimensional stability.
With a long-term operating temperature range of up to 240°C, PPS GF40 is suitable for use in a wide range of industrial applications where high performance and durability are essential. Its excellent strength and stiffness make it ideal for use in automotive, aerospace, and electronics industries, where it can be used to manufacture parts such as engine components, electronic housings, and connectors.
PPS GF40 is also highly resistant to chemical and thermal stress, making it suitable for use in harsh environments such as those found in chemical processing plants and oil refineries. It is also an excellent electrical insulator and can be used to produce insulation components for high voltage electrical systems.
In addition to its high-performance properties, PPS GF40 is also a low-friction material, making it ideal for use in sliding components that require minimal wear and high durability. The material is also highly resistant to creep and maintains its dimensional stability even under prolonged stress.
Overall, PPS GF40 is an excellent choice for applications that require high strength, durability, and heat resistance. Its unique combination of properties makes it suitable for use in a wide range of industries and applications where performance and reliability are essential.
Specification of PEEK Rod produced in Zero Engineering Plastic
| PEEK (PolyEtherEtherKetone) Semimanufacture Trademark: ZECAN@ Unit：mm,g/cm³ | |||||
| Virgin-PEEK ROD | Grade | Diameter | Longth | Gravity | Color |
| Virgin Grade | 6,8,10,12,15 | 1000/3000 | 1.32 |
Natutal Black |
|
| Virgin Grade | 18,20,25,,28,30 | 1000/3000 | 1.32 | ||
| Virgin Grade | 35-85 | 1000/3000 | 1.32 | ||
| Virgin Grade | 90,100,110,120,130,140 | 1000/3000 | 1.32 | ||
| Virgin Grade | 150,160,170,180,200,210,220 | 1000 | 1.32 | ||
Performance Parameter Table of PEEK Rod
| Test Item | Test Method | Result | |
| Tensile test | ISO 527-1:2012&ISO 527-2:2012 | Tensile Strength | 97MPa |
| Elongation at Break | 12.60% | ||
| Flexural Test | ISO 178:2019 Method A | Flexural stress at conventional deflection | 119MPa |
| Maximum flexural stress | 156MPa | ||
| Flexural Modulus | 3364MPa | ||
| Charpy Notched Impact Strength | ISO 179-1:2010 | 3.7KJ/㎡ C(complete destruction) | |
| Rockwell Hardness | ISO 2039-2:1987 | 112 | |
| Specific Gravity | ISO 1183-1:2019 Method A | 1.302 | |
| Water Absorption | ISO 62:2008 Method 1 | 0.06% | |
| Vertical Burning | UL 94-2013 Rev.9-2018 Section 8 | V-0 | |
| Mean Coefficient of Linear Thermal Expansion | ISO 11359-1:2014&ISO 11359-2:1998 Method A | 100~120℃ | 59×10-6K-1 |
| 140~200℃ | 173×10-6K-1 | ||
| Deflection Temperature under Load | ISO 75-1:2020&ISO 75-2:2013 Method A | 181℃ | |
| Melting extrapolated onset temperature, Teim | ISO 11357-3:2018 | 323.7℃ | 325.6℃ |
| Melting peak temperature, Tpm | 339.9℃ | 341.3℃ | |
| Melting extrapolated end temperature, Tefm | 348.3℃ | 347.2℃ | |
Hot Tags: pps gf40 sheet 8mm, China pps gf40 sheet 8mm manufacturers, suppliers, fabric pet carrier 4 short metal rods, pet plastic rods, pet plastic solid rod, pet rod stock
