Peek Rod Natural
Unit Price:$68.00-$78.00/kg
Have machined into semimanufacture rods and sheets. Unfilled PEEK comes in natural and black colors. Stocked materials typically ship in 5-7 business days.
Zhejiang Zero Engineering Plastics Co., Ltd. is one of the leading manufacturers and suppliers of peek rod natural in China. If you're going to wholesale bulk advanced peek rod natural made in China, welcome to get free sample from our factory. All customized products are with high quality and competitive price.
Definition:
Unfilled natural PEEK offers a continuous use temp 480°F (250°C) and high strength, low moisture absorption, it is electrically insulative, with a V-0 flammability rating and exhibits very low smoke and toxic gas emission when exposed to flame. Unfilled PEEK is FDA compliant. PEEK (Unfilled) general purpose grade is unreinforced and offers the highest elongation and toughness of all PEEK grades.
Main Features
●High Temperature Performance (480F Continuous Use)
●Mechanical Strength
●Dimensional Stability
●Excellent Chemical Resistance
●Low Smoke & Toxic Gas Emission
●Carbon Filled & Bearing Grades offer Excellent Wear Properties
Applications:
Back Up Rings
Electrical Components
Electrical Connectors
Manifolds
Pump & Valve Components
Semiconductor Components
Valve Seats
Specification of PEEK Rod Natural in Zero
Grade: Virgin Material
Diameter: 6/8/10/12/15/18/20/25/28/30/35~85/90~250mm
Sizes: Regular length is 1000mm or 3000mm
Density:1.32g/cm³
Color: Natural or Black
Parameter of Virgin PEEK Rod Natural as following table:
|
Test Item |
Test Method |
Result |
|
|
Tensile test |
ISO 527-1:2012&ISO 527-2:2012 |
Tensile Strength |
97MPa |
|
Elongation at Break |
12.60% |
||
|
Flexural Test |
ISO 178:2019 Method A |
Flexural stress at conventional deflection |
119MPa |
|
Maximum flexural stress |
156MPa |
||
|
Flexural Modulus |
3364MPa |
||
|
Charpy Notched Impact Strength |
ISO 179-1:2010 |
3.7KJ/㎡ C（complete destruction) |
|
|
Rockwell Hardness |
ISO 2039-2:1987 |
112 |
|
|
Specific Gravity |
ISO 1183-1:2019 Method A |
1.302 |
|
|
Water Absorption |
ISO 62:2008 Method 1 |
0.06% |
|
|
Vertical Burning |
UL 94-2013 Rev.9-2018 Section 8 |
V-0 |
|
|
Mean Coefficient of Linear Thermal Expansion |
ISO 11359-1:2014&ISO 11359-2:1998 Method A |
100~120℃ |
59×10-6K-1 |
|
140~200℃ |
173×10-6K-1 |
||
|
Deflection Temperature under Load |
ISO 75-1:2020&ISO 75-2:2013 Method A |
181℃ |
|
|
Melting extrapolated onset temperature, Teim |
ISO 11357-3:2018 |
323.7℃ |
325.6℃ |
|
Melting peak temperature, Tpm |
339.9℃ |
341.3℃ |
|
|
Melting extrapolated end temperature, Tefm |
348.3℃ |
347.2℃ |
|
Our Advantage:
Advanced CNC equipment
Professional Staff
Our Achievement:
Zero has designed the first set of special plastic sheet extrusion production line in China, filling the gap of such production equipment in China.
FAQ:
Q1: What length do you have for PEEK rod ?
Reply: Our regular length is 1000/2000/3000 mm.
Q2: What about the packing ?
Reply: For packing, our fumigation export wooden case can afford 1200 kgs 50 mm POM bar, so we suggest that one time you order 1200 kgs 50 mm POM bar in total at least, then we can offer fumigation export wooden case for free.
Q3:What about the qty of a full wooden cade.
Reply:We need to know your needed dimensions to caculate, usually, it suggested to order a qty can fill full of the case, in this way, the wooden case cost will be free to you.
Q4:Can you provide the free sample?
Reply: In general, we can provide you free sample to check and confirm, sample can be free if it’s small and freight shall be charged by your side.
